| Audio |
Realtek® ALC897 HD Audio, 5.1 Channel |
| Bluetooth свързаност |
5.3 |
| Chipset |
AMD® B850 |
| Connectors |
DisplayPort x1, HDMI x1 |
| CPU's supported |
Supports AMD Socket AM5 Processors including Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Form Factor |
Micro-ATX, 244x244mm |
| LAN |
Realtek® RTL8125BG 2.5 Gigabit Ethernet |
| Ram памет - вид |
4x DIMMS, Dual Channel DDR5, Maximum Memory Capacity 256GB (4x 64GB), up to 7600 MHz(OC) |
| Storage |
1x PCIe 5.0 M.2, 1x PCIe 4.0 M.2, 4x SATA |
| USB |
1x USB 3.2 Gen1 (1 x Type-C), 1x USB 3.2 Gen1 (2 x Type-A), 2x USB 2.0 (4 x Type-A) |
| Безжична свързаност |
M.2 WiFi 6 Module, Support 802.11 a/b/g/n/ac/ax, 2.4 GHz/ 5 GHz band, Bluetooth 5.3 Support |
| Други |
Debug LED: DRAM: Yellow, CPU: Red, GPU: White, Boot: Green |
| Интерфейси |
1× HDMI™, 1× DisplayPort, 6× USB 2.0, 2× USB 3.2 Gen1 Type-A, 1× RJ45 LAN, 2× Wi Fi Antennas, 3× Audio Jacks |
| Операционна система |
Windows 10/11 - 64 Bit |
| Производител |
SAPPHIRE |
| Слотове за памет |
1x PCIe 4.0 x16, 1x PCIe 4.0 x4 |
