| Cache |
L1 Cache: 960 KB;L2 Cache: 12 MB;L3 Cache: 64 MB |
| Connectivity |
Native USB 3.2 Gen 2 (10Gbps): 4;Native USB 2.0 (480Mbps): 1;PCI Express® Version: PCIe® 5.0;Additional Usable PCIe Lanes from Motherboard;X870E: 8x Gen4;X870: 4x Gen4;X670E: 12x Gen4;X670: 12x Gen4;B650E: 8x Gen4;B650: 8x Gen4;NVMe Support: Boot , RAID0 , RAID1 , RAID5 , RAID10 |
| Fan |
Not included |
| Memory Specifications |
System Memory Type: DDR5;Memory Channels: 2;Max. Memory: 192 GB;System Memory Subtype: UDIMM;Max Memory Speed: 2x1R-DDR5-5600;2x2R-DDR5-5600;4x1R-DDR5-3600;4x2R-DDR5-3600 |
| Native PCIe Lanes |
Total 28 /Usable 24 |
| Number of cores |
12 |
| OS Support |
Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
| Socket |
AM5 |
| Threads |
24 |
| Tray |
Yes |
| Видео карта |
AMD Radeon™ Graphics 2 2200 MHz;USB Type-C® DisplayPort™ Alternate Mode |
| Гаранция |
36 Months |
| Производител |
AMD |
| Термична мощност TDP |
120W |
| Честоти |
Max. Boost Clock: Up to 5.6 GHz;Base Clock: 4.4 GHz |
