| Audio |
Realtek® ALC897 Codec;7.1-Channel High Definition Audio |
| Bluetooth свързаност |
5.4 |
| Chipset |
INTEL Z890 |
| Connectors |
1x Thunderbolt5 card connector(JTBT5, support RTD3);1x Power Connector(ATX_PWR);2x Power Connector(CPU_PWR);1x Power Connector(PCIE_PWR 8pin);1x CPU Fan;1x Combo Fan (Pump_Sys Fan);4x System Fan;2x Front Panel (JFP);1x Chassis Intrusion (JCI);1x Front Audio (JAUD);1x Tuning Controller connector(JDASH);3x Addressable V2 RGB LED connector (JARGB_V2);1x RGB LED connector(JRGB);1x TPM pin header(Support TPM 2.0);4x USB 2.0 ports;2x USB 5Gbps Type A ports;1x USB 20Gbps Type C ports |
| CPU's supported |
Supports Intel® Core™ Ultra Processors (Series 2) LGA 1851 |
| Features |
4x EZ Debug LED |
| Form Factor |
ATX 243.84mmx304.8mm |
| I/O |
1x Thunderbolt4 ports (Rear);Supports up to 40Gbps transfer rate with Thunderbolt devices;Supports up to 20Gbps transfer rate with USB4 devices;Supports up to 10Gbps transfer rate with USB 3.2 devices;Supports up to 5V/3A,15W power charging;Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices;Supports up to 8K display;4x USB 2.0 (Front);6x USB 5Gbps Type A (Rear);2x USB 5Gbps Type A (Front);1x USB 20Gbps Type C (Rear);1x USB 20Gbps Type C (Front) |
| LAN |
Realtek® 8125D 2.5Gbps LAN |
| Ram памет - вид |
4x DDR5 UDIMM, Maximum Memory Capacity 256GB;Memory Support 8600 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s;Max. overclocking frequency:;• 1DPC 1R Max speed up to 8600+ MT/s;• 1DPC 2R Max speed up to 7200+ MT/s;• 2DPC 1R Max speed up to 4800+ MT/s;• 2DPC 2R Max speed up to 4800+ MT/s;Supports Intel® POR Speed and JEDEC Speed;Supports Memory Overclocking and Intel® XMP 3.0;Supports Dual-Controller Dual-Channel mode;Supports Non-ECC, Un-buffered memory;Supports CUDIMM |
| Storage |
3x M.2;-M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices;-M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices;-M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G;Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices;Supports RAID 0, RAID 1, RAID 5 for M.2 NVMe storage devices |
| Безжична свързаност |
Intel® Wi-Fi 7;The Wireless module is pre-installed in the M.2 (Key-E) slot;Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps;Supports 802.11 a/ b/ g/ n/ ac/ ax/ be |
| Видео карта |
1x HDMI™;Support HDMI™ 2.1, maximum resolution of 4K 60Hz;1x DisplayPort;Support DisplayPort 1.4, maximum resolution of 4K 60Hz;1x Type-C DisplayPort;Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz |
| Гаранция |
36 Months |
| Операционна система |
Support for Windows® 11 64-bit |
| Производител |
MSI |
| Слотове за памет |
4x PCI-E x16 slot;-PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU);-PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset);-PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset);-PCI_E4 Gen PCIe 4.0 supports up to x4 (From CPU) |
